SDR Analog FPV Receiver
Transform your computer into an FPV video receiver and scanner with Analog FPV. Built with a focus on performance, this application receives and decodes analog video transmissions in real-time. Analog FPV also supports color decoding and custom scanning to build awareness of FPV drones operating within range of your software-defined radio (SDR). This small but highly efficient program requires a minimal number of software dependencies and supports the HackRF One and BladeRF. Analog FPV is sold with a perpetual license with no subscription fees.
Features
- Full-Color NTSC and PAL Decoding - GPU-accelerated color pipeline with adaptive filtering and burst-locked demodulation
- Multi-Channel Scanning - Automatically scan and monitor custom channel ranges using a compatible software-defined radio
- Professional SDR Support - Compatible with BladeRF and HackRF One software-defined radios
- Live Spectrum Waterfall - Real-time frequency visualization to identify active channels
- Advanced Video Controls - Adjustable brightness, contrast, and color saturation for optimal viewing
- Intuitive Interface - Modern GUI with zoom, panning, video preview thumbnails, channel grid, and diagnostic tools
System Requirements:
- Windows 10 or later (64-bit amd64) with a GPU that supports OpenGL
- Debian 11 (Bullseye) or later (64-bit amd64)
- Linux Mint 20 or later (64-bit amd64)
- At least 150 MB of RAM
NOTE: This is an early release of this software (version 0.1.9), and so there may be testing gaps and bugs. We will provide support and quickly respond to any reported issues via this form.
Applications
- Long-range FPV drone flying with software-defined radios
- Multi-pilot events and FPV racing competitions
- Detecting and monitoring FPV drones in proximity
- Video signal analysis and troubleshooting
We can provide customizations to this software to fit your specific application under contract services.
